Trituradora fina de plástico de doble eje
Esta trituradora fina de doble eje está diseñada específicamente para películas plásticas, sacos tipo "big bag", sacos tejidos, madera, libros y otros materiales de dureza media o blanda. El equipo emplea una configuración de doble eje sin sistema de empuje, lo que garantiza una gran flexibilidad operativa. El diseño exclusivo de la cámara de corte minimiza la fricción en los ejes. Los dos ejes contrarrotativos trituran los materiales de forma continua, mejorando la eficiencia y maximizando el rendimiento. El sistema de control PLC Siemens incluye funciones de arranque, parada e inversión automática del giro en caso de sobrecarga.
Trituradora fina de plástico de doble eje
La trituradora fina de doble eje está diseñada específicamente para procesar películas plásticas, sacos tipo *big bag*, sacos tejidos, madera, libros y otros materiales de dureza media o blanda. Cuenta con un diseño de doble eje sin empujador, lo que proporciona una mayor flexibilidad y una alimentación eficiente del material. El diseño exclusivo de la cámara de corte minimiza la fricción entre los ejes, contribuyendo a mejorar la eficiencia operativa y a prolongar la vida útil del equipo. Los dos ejes de rotación contraria trituran los materiales de forma continua, garantizando un procesamiento eficiente y maximizando el rendimiento. Equipada con un sistema de control PLC Siemens, la trituradora permite el arranque y la parada automáticos, así como la protección contra sobrecargas con inversión automática del sentido de giro, asegurando un funcionamiento estable, seguro y fiable.
Especificaciones técnicas y capacidad
| Model | 750 | 900 | 1100 | 1400 | 1600 | 2100 |
| Diámetro de rotación(mm) |
φ400 |
φ400 | φ400 | φ400 | φ480 | φ480 |
| Velocidad del eje principal(rpm) | 73 | 73 | 73 | 73 | 73 | 73 |
| N.º de cuchillas del rotor(pcs) | 39x2 | 45x2 | 57x2 | 69x2 | 54x2 | 69x2 |
| N.º de cuchillas del estator(pcs) | (12+2)x2 | (14+2)x2 | 20x2 | 24x2 | (17+2)x2 | 24x2 |
| Cámara de corte(mm) | 1100x768 | 1100x900 | 1100x1131 | 1100x1362 | 1220x1593 | 1220x2055 |
| Altura de descarga H1(mm) | 622 | 622 | 622 | 622 | 820 | 820 |
| Diámetro de la criba(mm) | Z40 | Z40 | Z40 | Z40 | Z60 |
Z60
|
| Potencia del motor(kW) | 2x37 | 2x45 | 2x55 | 2x75 | 2x110 | 2x160 |
| Dimensiones(mm) | 2701x2105x2151 | 2800x2105x2151 | 3520x2259x2151 | 3751x2259x2151 | 4100x1810x2630 | 4860x1810x2630 |
| Peso(kg) | Approx 5700 | Approx 5800 | Approx 7100 | Approx 7500 | Approx 11000 | Approx 13500 |
